DA-G2.Standard A2B | Network Preamp for Ford

The DA-G2.Standard A2B has been specifically designed for Ford B&O and Lincoln Revel systems to interface seamlessly into the infotainment network for unprecedented control and audio reproduction.

Blackfin DSP
The heart of the device is a 533MHz Blackfin Digital Signal Processor (DSP). With it, the DA-G2.Pro A2B is capable of concurrently running advanced DSP algorithms on up to 12 channels. It provides full access to channel mapping, channel summing, parametric crossovers, a 1024 point graphic equalizer, channel high/low/band-pass filters, phase inversion, time alignment, master/channel gain control, center channel upmixing algorithms, in-vehicle preset control, and many other features.

Burr-Brown
The pre-amp stage is driven by a Burr Brown DAC converter, providing audiophile quality without compromise.

Seamless Integration
The DA-G2.Pro A2B interfaces seamlessly with the controls of the vehicle. Volume, fade, balance, bass, and treble remain completely controllable via the existing vehicle controls, and all factory audio such as parking sensors, navigation, voice, and telephone are integrated to behave exactly as per the original system. This means that unlike other integration options, there is no need for mounting of any additional controls inside the vehicle. The vehicle will look and feel stock, with exceptional audio quality.

INPUT
Digital Input from the vehicle infotainment A2B+ network (also monitors vehicle CAN network)

OUTPUT
Ten analog RCA channels (3.6V RMS)

Frequency Response (analog or digital) 20 Hz-24 kHz

Signal-to-Noise Ratio (analog): 112dB

THD+N @-1dB FS: -107dB FS

32-bit Blackfin DSP w/crossovers, delay, EQ, and polarity inversion

POWER SUPPLY
Current Consumption:
Standby: <3mA
Operational: 350 mA nominal
Operational Voltage: 8V – 22V DC
Remote Turn On Capacity: 12V @ 500mA

OTHER

Dimensions 110mm x 80mm x 30mm

Weight 200g

Country of Origin Australia

• DA-G2 A2B Standard module
• Power and Speaker harnesses
• USB cable
• RCA output harness

Mobridge A2B Ford User Manual

Mobridge A2B Dipswitch Settings
