Zen 25 | MOST 25 Network Preamp for BMW
Zen 25 | MOST 25 Network Preamp for BMW
SKU:NTV-KIT969
Couldn't load pickup availability
The ZEN 25 is a network preamp and a DSP processor, compatible specifically with BMWs using MOST 25. BMW used MOST 25 on models over a wide range of years, and the Zen 25 covers 2004-2019 BMW with 677, 688, and 752 audio (see below for coverage specifics). Once the pure uncompressed 2-channel audio is extracted from the infotainment network, the Zen 25's DSP section can filter, equalize, level match, and delay the signal as needed. Zen 25 monitors the MOST network and applies volume control, front/rear fade (analog only), balance, treble, bass control, and the factory 7-band EQ! Chimes, alerts, and phone call audio are all integrated into the system.
The user interface, full independent control of phone and chime volumes, and full audio routing.
ZEN-25 includes a Toslink SPDIF output and 12 analog RCA output channels, with 6V RMS and a signal-to-noise ratio of 114dB.
Additional Product Information
Details
Please note that for plug-and-play operation, the vehicle must have a premium sound package MOST 25 amplifier. This means the BMW must have S677 Logic 7, S688 h/k, B&O, or S752 Individual Audio.
NOTE: If the vehicle lacks a premium sound package with a MOST 25 amplifier, it is technically possible to recode some BMW head units to enable MOST 25 networking. For example, if your BMW lists S677, S688, or S752 audio, there is an active MOST 25 network present at the nine-channel DSP amplifier. If your BMW lists S676 HiFi - or no sound package at all - there is no MOST 25 network amplifier in the system, and the vehicle would have to be retrofitted and recoded to support a MOST 25 amplifier for this Zen Audio product to work successfully. MOST 25 cabling will also have to be installed between the head unit and the Zen device.
Please note that such vehicle recoding is the responsibility of the installer and is not something Nav-TV can perform on behalf of the installer.
Specifications
INPUT
Digital Input - MOST 25 Fiber-optic
OUTPUT
12 analog RCA channels (6V RMS)
Frequency Response 18 hz-22.05kHz (analog out)
S/N Ratio (analog): 114 dB
THD+N @ -1dBFS -94 dB
Toslink SPDIF optical
POWER SUPPLY
Current Consumption:
Standby: <1 mA
Operational: 350 mA maximum
Operational Voltage: 7V – 20V DC
Remote Turn On Capacity: 500mA
OTHER
Dimensions (module): 4”x5”x1 3/8”
Weight (module) 10 oz
Country of Origin USA
What's Included
- Zen 25 module (NTV ASY-297)
- Zen RCA output harness (NTV -HAR315)
- MOST 25 connector shell NTV-CON002
- Zen Power Harness NTV-HAR316
- USB Cable NTV-CAB009
Product Support
Firmware Updates
FAQs
What makes this preamp sound so good?
Some of that is the Zen Audio network preamp technology (more on that here), and some of it is the audiophile-grade D/A converters and op-amps used in the signal path. This preamp was part of a world-champion award-winning sound system!
Does it work in all BMW?
It works in specific BMW vehicles that use the MOST 25 infotainment network technology. Please see the Vehicle Compatibility tab for specific coverage information.
Does it work in MOST 25 vehicles that are not BMW?
No, it does not. For those vehicles, please check the compatability listings for the Mobridge DA-G2 Pro (for DSP) or the Mobridge DA1 or DA-G2 Standard (without DSP). Note that the DA1 has only a Toslink stereo SPDIF output - for analog RCA outputs, use the DA-G2 Standard.
See the installation manual for more information.
